Robust, durable, and easy to use.

Trimble C5 - Total Station

Description

The Trimble C5 5" increases your productivity and decreases data capture time. Its compact, lightweight and robust design, its powerful long-range reflectorless measurement (EDM), coupled with "Autofocus" technology for precise and fast focusing, make it a reliable total station, designed to perform at the highest levels.

Specifications

Accuracy with prism: ±(2+2 ppm × D) mm
Accuracy without prism: ±(3+2 ppm × D) mm
Autofocus
Dual backlit LCD display (640 x 480 pixels)
Operating system: Windows® Embedded Compact 7
Processor: Dual Core 800 MHz
Point memory: 512 MB RAM, 4 GB Flash memory
Internal plummet: Optical or Laser Class 2
Optical plummet: Magnification: 3x
Field of view: 5°
Minimum focusing distance: 0.5 m
Dimensions (Width x Depth x Height): 206 mm x 169 mm x 318 mm
Weight (approx.) main unit: 4.3 kg





Includes

  • Total station

  • Fiber/wood tripod

  • Ranging pole

  • Prism


Video
Datasheet

Download Datasheet

Formulario de cotización

¿Necesitas más información de un producto? ¿Quieres solicitar una demo? Completa el formulario con tus datos y nos pondremos en contacto.
Characteristics

Trimble C5 5" aumenta su productividad y disminuye el tiempo para la captura de datos. Su diseño compacto, ligero y robusto, su potente medición sin prisma (EDM) de largo alcance, sumado a la tecnología “Autofocus” para un enfoque preciso y rápido, la convierten en una estación total confiable, para rendir al máximo a los niveles más altos.

Specifications

  • Prism accuracy4: ±(2+2 ppm × D) mm
  • Non-prism accuracy: ±(3+2 ppm × D) mm
  • Autofocus
  • Dual backlit LCD screen (640 x 480 pixels)
  • Operating system: Windows® Embedded Compact
  • Processor: Dual core 800 MHz
  • Point memory: 512 MB RAM, 4 GB Flash memory
  • Internal plummet: Optical or Class 2 Laser
  • Optical plummet: Magnification: 3x
  • Field of view: 5°
  • Minimum focusing distance: 0.5 m
  • Dimensions (Width x Depth x Height): 206 mm x 169 mm x 318 mm
  • Weight (approx.) main unit: 4.3 kg

Extend your work season.

For users working in cold temperatures, Trimble C5 total stations are available in a specially designed winter version that includes a display heater.
